S68R38減速機詳細信息

prevnext

S68R38減速機

訂購熱線：13360667204

詳細信息

S68R38減速機電機功率：S68R38Y0.12KW減速機,S68R38Y0.18KW減速機,S68R38Y0.25KW減速機,S68R38Y0.37KW減速機,S68R38Y0.55KW減速機（可配變頻電機，剎車電機，防爆電機，伺服電機，交流電機，直流電機，三相電機，單相電機）。

S68R38減速機配0.12KW電機參數

型號	減速比	功率	轉數	扭矩	重量	力矩	安全系數
S68R38-Y0.12KW	1194	0.12KW	1.20r/min	585N.m	40kg	7990N	0.95
S68R38-Y0.12KW	1045	0.12KW	1.30r/min	530N.m	40kg	8560N	1.05
S68R38-Y0.12KW	914	0.12KW	1.50r/min	455N.m	40kg	9180N	1.25
S68R38-Y0.12KW	809	0.12KW	1.70r/min	415N.m	40kg	9460N	1.35
S68R38-Y0.12KW	712	0.12KW	1.90r/min	365N.m	40kg	9780N	1.55
S68R38-Y0.12KW	615	0.12KW	2.20r/min	305N.m	40kg	10100N	1.85
S68R38-Y0.12KW	543	0.12KW	2.50r/min	275N.m	40kg	10200N	2.10
S68R38-Y0.12KW	469	0.12KW	2.90r/min	225N.m	40kg	10400N	2.50
S68R38-Y0.12KW	424	0.12KW	3.30r/min	200N.m	40kg	10500N	2.80
S68R38-Y0.12KW	365	0.12KW	3.80r/min	187N.m	40kg	10500N	3.00

S68R38減速機配0.18KW電機參數

型號	減速比	功率	轉數	扭矩	重量	力矩	安全系數
S68R38-Y0.18KW	712	0.18KW	1.90r/min	600N.m	40.5kg	7860N	0.95
S68R38-Y0.18KW	615	0.18KW	2.20r/min	505N.m	40.5kg	8800N	1.15
S68R38-Y0.18KW	543	0.18KW	2.40r/min	450N.m	40.5kg	9230N	1.25
S68R38-Y0.18KW	469	0.18KW	2.80r/min	375N.m	40.5kg	9720N	1.50
S68R38-Y0.18KW	424	0.18KW	3.10r/min	340N.m	40.5kg	9930N	1.65
S68R38-Y0.18KW	365	0.18KW	3.60r/min	305N.m	40.5kg	10100N	1.85

S68R38減速機配0.25KW電機參數

型號	減速比	功率	轉數	扭矩	重量	力矩	安全系數
S68R38-Y0.25KW	543	0.25KW	2.40r/min	650N.m	44.5kg	6280N	0.85
S68R38-Y0.25KW	469	0.25KW	2.80r/min	550N.m	44.5kg	8390N	1.05
S68R38-Y0.25KW	424	0.25KW	3.10r/min	495N.m	44.5kg	8880N	1.15
S68R38-Y0.25KW	365	0.25KW	3.60r/min	440N.m	44.5kg	9320N	1.30
S68R38-Y0.25KW	319	0.25KW	4.10r/min	380N.m	44.5kg	9700N	1.50
S68R38-Y0.25KW	281	0.25KW	4.60r/min	335N.m	44.5kg	9960N	1.70

S68R38減速機配0.37KW電機參數

型號	減速比	功率	轉數	扭矩	重量	力矩	安全系數
S68R38-Y0.37KW	365	0.37KW	3.80r/min	620N.m	45kg	7560N	0.90
S68R38-Y0.37KW	319	0.37KW	4.30r/min	540N.m	45kg	8450N	1.05
S68R38-Y0.37KW	281	0.37KW	4.90r/min	475N.m	45kg	9030N	1.20
S68R38-Y0.37KW	246	0.37KW	5.60r/min	430N.m	45kg	9380N	1.30

S68R38減速機配0.55KW電機參數

型號	減速比	功率	轉數	扭矩	重量	力矩	安全系數
S68R38-Y0.55KW	246	0.55KW	5.60r/min	645N.m	49.5kg	6520N	0.90
S68R38-Y0.55KW	221	0.55KW	6.20r/min	580N.m	49.5kg	8080N	1.00
S68R38-Y0.55KW	198	0.55KW	7.00r/min	525N.m	49.5kg	8590N	1.10
S68R38-Y0.55KW	168	0.55KW	8.20r/min	450N.m	49.5kg	9220N	1.25

S68R38減速器減速比：168比蝸輪蝸桿減速機,198比減速器,221比減速器,246比減速器,281比減速器,319比減速器,365比減速器,424比減速器,469比減速器,543比減速器,615比減速器,712比減速器,809比減速器,914比減速器,1045比減速器,1194比減速器。

S68R38減速機電機安裝尺寸：輸出軸+鍵Φ38（可定做），高236*寬250（帶輸出軸）*長398

S68R38減速電機輸出轉數：1.2轉減速電機,1.3轉減速電機,1.5轉減速電機,1.7轉減速電機,1.9轉自鎖減速機,2.2轉減速電機,2.4轉減速電機,2.5轉減速電機,2.8轉減速電機,2.9轉減速電機,3.1轉減速電機,3.3轉減速電機,3.6轉減速電機,3.8轉減速電機,4.1轉減速電機,4.3轉減速電機,4.6轉減速電機,4.9轉減速電機,5.6轉減速電機,6.2轉減速電機,7轉減速電機,8.2轉減速電機。

S68R38減速箱電機輸出扭矩：187N.m減速箱,200N.m減速箱,225N.m減速箱,275N.m減速箱,305N.m減速箱,335N.m減速箱,340N.m減速箱,365N.m減速箱,375N.m減速箱,380N.m減速箱,415N.m減速箱,430N.m減速箱,440N.m減速箱,450N.m減速箱,455N.m減速箱,475N.m減速箱,495N.m減速箱,505N.m減速箱,525N.m減速箱,530N.m減速箱,540N.m減速箱,550N.m減速箱,580N.m減速箱,585N.m減速箱,600N.m減速箱,620N.m減速箱,645N.m減速箱,650N.m減速箱。

S68R38減速機電機各種輸出實物圖：

S68R38減速馬達型號：

SHZ67R37DM63L4,SHZ67R37DM63M4,SHZ67R37DM63MS4,SHZ67R37DM63S4,SHZ67R37DM71D4,SHZ67R37DM71M4,SHZ67R37DM71MS4,SHZ67R37DM71S4,SHZ67R37DM80K4,SHZ67R37DM80M4,SHZ67R37DM80MK4,SHZ67R37DM80N4,SHZ67R37DM80S4,SHZ67R37DR63L4,SHZ67R37DR63M4,SHZ67R37DR63MS4,SHZ67R37DR63S4,SHZ67R37DR71D4,SHZ67R37DR71M4,SHZ67R37DR71MS4,SHZ67R37DR71S4,SHZ67R37DR80K4,SHZ67R37DR80M4,SHZ67R37DR80MK4,SHZ67R37DR80N4,SHZ67R37DR80S4,SHZ67R37DRE63L4,SHZ67R37DRE63M4,SHZ67R37DRE63MS4,SHZ67R37DRE63S4,SHZ67R37DRE71D4,SHZ67R37DRE71M4,SHZ67R37DRE71MS4,SHZ67R37DRE71S4,SHZ67R37DRE80K4,SHZ67R37DRE80M4,SHZ67R37DRE80MK4,SHZ67R37DRE80N4,SHZ67R37DRE80S4,SHZ67R37DRN63L4,SHZ67R37DRN63M4,SHZ67R37DRN63MS4,SHZ67R37DRN63S4,SHZ67R37DRN71D4,SHZ67R37DRN71M4,SHZ67R37DRN71MS4,SHZ67R37DRN71S4,SHZ67R37DRN80K4,SHZ67R37DRN80M4,SHZ67R37DRN80MK4,SHZ67R37DRN80N4,SHZ67R37DRN80S4,SHZ67R37DRS63L4,SHZ67R37DRS63M4,SHZ67R37DRS63MS4,SHZ67R37DRS63S4,SHZ67R37DRS71D4,SHZ67R37DRS71M4,SHZ67R37DRS71MS4,SHZ67R37DRS71S4,SHZ67R37DRS80K4,SHZ67R37DRS80M4,SHZ67R37DRS80MK4,SHZ67R37DRS80N4,SHZ67R37DRS80S4,SHZ67R37DT63L4,SHZ67R37DT63M4,SHZ67R37DT63MS4,SHZ67R37DT63S4,SHZ67R37DT71D4,SHZ67R37DT71M4,SHZ67R37DT71MS4,SHZ67R37DT71S4,SHZ67R37DT80K4,SHZ67R37DT80M4,SHZ67R37DT80MK4,SHZ67R37DT80N4,SHZ67R37DT80S4,SHZ67R37DV63L4,SHZ67R37DV63M4,SHZ67R37DV63MS4,SHZ67R37DV63S4,SHZ67R37DV71D4,SHZ67R37DV71M4,SHZ67R37DV71MS4,SHZ67R37DV71S4,SHZ67R37DV80K4,SHZ67R37DV80M4,SHZ67R37DV80MK4,SHZ67R37DV80N4,SHZ67R37DV80S4,SHZ67R37DVE63L4,SHZ67R37DVE63M4,SHZ67R37DVE63MS4,SHZ67R37DVE63S4,SHZ67R37DVE71D4,SHZ67R37DVE71M4,SHZ67R37DVE71MS4,SHZ67R37DVE71S4,SHZ67R37DVE80K4,SHZ67R37DVE80M4,SHZ67R37DVE80MK4,SHZ67R37DVE80N4,SHZ67R37DVE80S4,SHZ67RF37-Y0.12KW,SHZ67RF37-Y0.18KW,SHZ67RF37-Y0.25KW,SHZ67RF37-Y0.37KW,SHZ67RF37-Y0.55KW,SHZ67RF37-Y63M4,SHZ67RF37-Y71M4,SHZ67RF37-Y80M4,SHZ67RF37-YEJ0.12KW,SHZ67RF37-YEJ0.18KW,SHZ67RF37-YEJ0.25KW,SHZ67RF37-YEJ0.37KW,SHZ67RF37-YEJ0.55KW,SHZ67RF37-YEJ63M4,SHZ67RF37-YEJ71M4,SHZ67RF37-YEJ80M4,SHZ67RF37-YVP0.12KW,SHZ67RF37-YVP0.18KW,SHZ67RF37-YVP0.25KW,SHZ67RF37-YVP0.37KW,SHZ67RF37-YVP0.55KW,SHZ67RF37-YVP63M4,SHZ67RF37-YVP71M4,SHZ67RF37-YVP80M4,SHZ67RF37-YVPEJ0.12KW,SHZ67RF37-YVPEJ0.18KW,SHZ67RF37-YVPEJ0.25KW,SHZ67RF37-YVPEJ0.37KW,SHZ67RF37-YVPEJ0.55KW,SHZ67RF37-YVPEJ63M4,SHZ67RF37-YVPEJ71M4,SHZ67RF37-YVPEJ80M4,SAZ67R37DM63L4,SAZ67R37DM63M4,SAZ67R37DM63MS4,SAZ67R37DM63S4,SAZ67R37DM71D4,SAZ67R37DM71M4,SAZ67R37DM71MS4,SAZ67R37DM71S4,SAZ67R37DM80K4,SAZ67R37DM80M4,SAZ67R37DM80MK4,SAZ67R37DM80N4,SAZ67R37DM80S4,SAZ67R37DR63L4,SAZ67R37DR63M4,SAZ67R37DR63MS4,SAZ67R37DR63S4,SAZ67R37DR71D4,SAZ67R37DR71M4,SAZ67R37DR71MS4,SAZ67R37DR71S4,SAZ67R37DR80K4,SAZ67R37DR80M4,SAZ67R37DR80MK4,SAZ67R37DR80N4,SAZ67R37DR80S4,SAZ67R37DRE63L4,SAZ67R37DRE63M4,SAZ67R37DRE63MS4,SAZ67R37DRE63S4,SAZ67R37DRE71D4,SAZ67R37DRE71M4,SAZ67R37DRE71MS4,SAZ67R37DRE71S4,SAZ67R37DRE80K4,SAZ67R37DRE80M4,SAZ67R37DRE80MK4,SAZ67R37DRE80N4,SAZ67R37DRE80S4,SAZ67R37DRN63L4,SAZ67R37DRN63M4,SAZ67R37DRN63MS4,SAZ67R37DRN63S4,SAZ67R37DRN71D4,SAZ67R37DRN71M4,SAZ67R37DRN71MS4,SAZ67R37DRN71S4,SAZ67R37DRN80K4,SAZ67R37DRN80M4,SAZ67R37DRN80MK4,SAZ67R37DRN80N4,SAZ67R37DRN80S4,SAZ67R37DRS63L4,SAZ67R37DRS63M4,SAZ67R37DRS63MS4,SAZ67R37DRS63S4,SAZ67R37DRS71D4,SAZ67R37DRS71M4,SAZ67R37DRS71MS4,SAZ67R37DRS71S4,SAZ67R37DRS80K4,SAZ67R37DRS80M4,SAZ67R37DRS80MK4,SAZ67R37DRS80N4,SAZ67R37DRS80S4,SAZ67R37DT63L4,SAZ67R37DT63M4,SAZ67R37DT63MS4,SAZ67R37DT63S4,SAZ67R37DT71D4,SAZ67R37DT71M4,SAZ67R37DT71MS4,SAZ67R37DT71S4,SAZ67R37DT80K4,SAZ67R37DT80M4,SAZ67R37DT80MK4,SAZ67R37DT80N4,SAZ67R37DT80S4,SAZ67R37DV63L4,SAZ67R37DV63M4,SAZ67R37DV63MS4,SAZ67R37DV63S4,SAZ67R37DV71D4,SAZ67R37DV71M4,SAZ67R37DV71MS4,SAZ67R37DV71S4,SAZ67R37DV80K4,SAZ67R37DV80M4,SAZ67R37DV80MK4,SAZ67R37DV80N4,SAZ67R37DV80S4,SAZ67R37DVE63L4,SAZ67R37DVE63M4,SAZ67R37DVE63MS4,SAZ67R37DVE63S4,SAZ67R37DVE71D4,SAZ67R37DVE71M4,SAZ67R37DVE71MS4,SAZ67R37DVE71S4,SAZ67R37DVE80K4,SAZ67R37DVE80M4,SAZ67R37DVE80MK4,SAZ67R37DVE80N4,SAZ67R37DVE80S4,SAZ67RF37-Y0.12KW,SAZ67RF37-Y0.18KW,SAZ67RF37-Y0.25KW,SAZ67RF37-Y0.37KW,SAZ67RF37-Y0.55KW,SAZ67RF37-Y63M4,SAZ67RF37-Y71M4,SAZ67RF37-Y80M4,SAZ67RF37-YEJ0.12KW,SAZ67RF37-YEJ0.18KW,SAZ67RF37-YEJ0.25KW,SAZ67RF37-YEJ0.37KW,SAZ67RF37-YEJ0.55KW,SAZ67RF37-YEJ63M4,SAZ67RF37-YEJ71M4,SAZ67RF37-YEJ80M4,SAZ67RF37-YVP0.12KW,SAZ67RF37-YVP0.18KW,SAZ67RF37-YVP0.25KW,SAZ67RF37-YVP0.37KW,SAZ67RF37-YVP0.55KW,SAZ67RF37-YVP63M4,SAZ67RF37-YVP71M4,SAZ67RF37-YVP80M4,SAZ67RF37-YVPEJ0.12KW,SAZ67RF37-YVPEJ0.18KW,SAZ67RF37-YVPEJ0.25KW,SAZ67RF37-YVPEJ0.37KW,SAZ67RF37-YVPEJ0.55KW,SAZ67RF37-YVPEJ63M4,SAZ67RF37-YVPEJ71M4,SAZ67RF37-YVPEJ80M4。
